Features:


1. Support Card: ATM/CAC/ID/IC/SIS/Credit Cards

2. Supported Card Types: 5V, 3V and 1.8V Smart Cards ISO 7816 Class A, B and C

3. Standard: ISO 7816 & EMV Level 1 & T=0 and T=1 Protocols

4. Host Interface: USB 2.0 CCID1 (also compliant with USB 1.1)

5. Smart Card Interface Speed: 420 Kbps (when supported by card)

6. Power Supply: Bus Powered

7. PC/SC Driver Support:

Windows® 98 / ME, 200 / XP (32bit), 2003 Server

Windows® CE 5.0 (depending on hardware)

Windows® Vista (32bit / 64bit)

Windows® 7 and Above

Linux®

Standard Compliance

Support EMV Level 1 specification

Support USB 2.0 full speed

Based on ISO7816 implementation

Support PC Smart Card industry standard – PC/SC 2.0

Support Microsoft Smart Card for Windows

Meet Microsoft WHQL USB Smart Card Reader requirements

Meet US Federal Information Processing Standards (FIPS) Publication 201

requirements on smart card reader interoperability

Support single slot

Support T0, T1 protocol

Support I2C memory card, SLE4418, SLE4428, SLE4432, SLE4442, SLE4436,

SLE5536, SLE6636, AT88SC1608, AT45D041 card and AT45DB041 card via

external EEPROM

Support ISO7816 Class A, B and C (5V/3V/1.8V) card

Implemented as an USB full speed device with bulk transfer endpoint, Mass

Storage endpoint

Built-in PLL for USB and Smart Card clocks requirement

Support EEPROM for USB descriptors customization (PID/VID/ iManufacturer/

iProduct/Serial Number), Direct Web Page Link, and accessing memory card

module.

EEPROM programmable via USB interface

Support software update for memory card module

Support Direct Web Page Link via configuration in external EEPROM

Support short APDU and extended APDU

Compatible with Microsoft USB-CCID driver

Support remote wake up through inserting card/removing card

Support USB selective suspend

Support Power Saving Mode (Using one pin to select between Normal/PWR

Saving Mode)
